Summit Marine




Overview: Cylinders – 2.5” bore x 20” stroke, dual acting. PATENTED Retract lift system. Pump System – Monarch Fluid Power, 2,500 psi, 4 way valve, 12 volt system. 1/4” hose assemblies. Fluid – Completely biodegradable.

Hydraulic Boat Lift Specifications

Model HL 4400 Pontoon HL 4400P HL 6000 HL 8000 HL 12000 HL14/18/24
Capacity # 4,400 4,400 6,000 8,000 12,000 14000 to 24000
Lift Height 40 40 40 40 40 40
Weight – frame only 243 243 303 397 550 1200+
weight – cylinders 52 52 104 104 156 156+
Beam Width 114 114 120 132 132 150
Bunk Length 120 192 144 168 192 216-264
Power Source (not included) 1@12 volt 1@12 volt 1@12 volt 1@12 volt 2@12 volt 24 volt
 Water Depth 18″ + 1/2 of boat draw for all models. Pontoon requires 0″ with 40″ beam, 6″ with 120″ beam.


Features and Benefits

  Strong lightweight marine grade 6005 aluminum. Years of trouble free service.

  • Strong 2 x 6 tube used for beam members. 33% stronger than 2 x 5, and 56% stronger than 2 x 4.5”.
  • Stainless Steel hardware. Eliminates rusting problems, eliminates premature failure from worn pins.
  • Monarch Fluid Pump System. Well recognized and trusted name in the industry, thoroughly tested.
  • Patented Retract Lift System. Cylinders close as the lift elevates – protecting cylinders from scale buildup and Zebra Mussel problems, the # 1 cause for premature cylinder failure. US Patent 5,890,835.
  • Larger cylinders than its competitors. Allows for 32% reduction in working pressure. Less wear on gears, motor, hoses, fittings and cylinder seals (the #2 cause for cylinder failure). Less strain on the pump motor translates to greater battery life.
  • 12 volt power. Safe, clean power at the lake shore.
  • Quick disconnects keyed one way. Easy to disconnect, reconnection cannot be done wrong.
  • Biodegradable fluid. Same high quality power fluid used by the logging industry to protect our forests.
  • Swivel bunk supports. Adjust to your hull’s dead rise.
  • Changeable foot pad tube. Allows the customer to change the foot height tube without purchasing the whole assembly.
  • Interchangeable leg assembly. Less expensive to change to canopy uprights later or change beam widths.


PRICING
#1,000 SINGLE PWC LIFT STARTING AT    $             6,033.95
#1,200 SINGLE PWC LIFT STARTING AT    $             6,611.58
#1,000 DOUBLE PWC LIFT STARTING AT    $           10,279.71

#4,400 PONTOON LIFT STARTING AT    $           10,148.80
#5,000 PONTOON LIFT STARTING AT    $           10,988.23
#6,000 PONTOON LIFT STARTING AT    $           12,753.48
#7,000 PONTOON LIFT STARTING AT    $           13,935.72

#4,400 BOAT LIFT STARTING AT    $             9,393.03
#5,000 BOAT LIFT STARTING AT    $           10,232.48
#6,000 BOAT LIFT STARTING AT    $           11,914.04
#7,000 BOAT LIFT STARTING AT    $           13,096.26
#8,000 BOAT LIFT STARTING AT    $           15,812.96
#10,000 120″ BEAM BOAT LIFT STARTING AT    $           19,662.48
#10,000 132″ BEAM BOAT LIFT STARTING AT    $           19,770.56
#12,000 120″ BEAM BOAT LIFT STARTING AT    $           21,386.68
#12,000 132″ BEAM BOAT LIFT STARTING AT    $           21,517.71
#14,000 150″ BEAM BOAT LIFT STARTING AT    $           38,868.88
#18,000 150″ BEAM BOAT LIFT STARTING AT    $           54,561.03
#24,000 150″ BEAM BOAT LIFT STARTING AT    $           67,703.35
#30,000 150″ BEAM BOAT LIFT STARTING AT    $           93,474.60
